BANDSAW FB 940 RS FELDER

The BANDSAW FB 940 RS FELDER has a cutting height of 550mm, a cutting width of 910mm and a steering wheel of 940mm diameter. The cutting speed is 1950 m/min. The dimensions of the table are 860 x 1100mm. It has feeder opening with pneumatic balancing, optional.

More details

FB 940 RS FELDER
New machinery

Technical description

BANDSAW FB 940 RS FELDER

The FB 940 RS model has a closed frame of the solid steel construction machine, heavy cast and bulged cast iron, permanent cleaning of the band saw blades, roller support in front of the machine table. It allows great heights of cut obtaining a homogeneous result of cut thanks to an automatic feeding. Possible application of 4 different feeders, feed speeds of up to 40 m/min and allows the inclination of the sanding table 20 °.

TECHNICAL DATA

Unit

  • Cutting height in mm: 550
  • Cutting width in mm: 910
  • Flywheel-Ø in mm: 940
  • Cutting speed in m/min: 1950

General

  • Table size in mm: 860 x 1100
  • Total height in mm: 2900
  • Dust port Ø in mm: 2x 140
  • Weight kg (with standard configuration): 830

Characteristics for information only. The technical details are not legally binding. Contact us for further information.
